1982-2002 Chevrolet UMI Rear Drag Sway Bar, 3-1/4 Inch Axle Tubes, Black 2245-325-B

Say goodbye to leaving the line sideways with UMI's rear drag bar set-up. This rear drag bar is designed to get your Camaro leaving the line straight, eliminate torque steer and drastically improve 60-foot times as well as consistency. The rear drag bar is manufactured from 1.25 inch solid 4140 Chrome Moly steel, heat treated and formed as one piece to insure maximum strength and performance. The included adjustable end links allow vehicle pre-load to be set for straight launches. Our end links feature heavy duty chrome moly rod ends which feature a hard chrome plating and a Teflon self lubricating race. The end links attach to the drag bar using 5/8 inch grade 8 bolts and lock nuts. The heavy duty rear drag bar attaches to the axle tubes using high strength 4140 chrome moly u-bolts, 3/16 inch thick fabricated mounts and Energy Suspension bushings. The fabricated bushing mounts feature CNC machined teeth to prevent sliding on the axle. Also Unlike the competitors design UMI's sway bar mounts also feature gussets welded on each end to prevent the brackets from spreading while tightening.Installation: This kit is a bolt-in design and bolts to existing factory mounting holes. Although the kit is 100% bolt-in, we recommend welding the brackets to the frame with the axle tubes being optional. This allows the user to install the product and drive it to a shop for the small amount of welding. Kit includes all hardware needed for this 2 hour installation.Features:1.250 inch solid 4140 chrome moly anti-roll barHeavy duty 5/8 inch chrome moly spherical rod ends with Teflon raceHigh strength 4140 chrome moly zinc plated steel 7/16 inch u-boltsCNC machined sway bar mounts with grip teeth and gussetsHex billet aluminum adjusterEnergy Suspension polyurethane bushingsDurable long lasting powder coatAxle Tube Diameters:Strange Engineering and Currie rear ends use 3 inch diameter axle tubesMoser Engineering 12-bolt rear ends use 3 inch diameter axle tubesMoser Engineering 9 inch rear ends manufactured after early 2002 use 3 inch axle tubes. Rear ends manufactured prior to early 2002 use 3.25 inch axle tubes. Please verify diameter before ordering.Other brand rear ends will vary, please check your axle tube diameter before ordering

Manufacturer Part Number : 2245-325-B
